Solar 3D Design Services

Solar 3D Design Services in Pakistan

Solar Design Services

We are providing solar 3D designs and drawings as per the client requirements and needs, across Pakistan.

Our core design services include:

Solar 3D Structural Visualization

Our Solar 3D structural visualization service offers 3D representations of solar panel mounting structures for future prospect. These visualization help understand the different types of mounting structure (such as elevated, ground mounted, roof mounted etc) placement and area covered by solar panels on given space for fabrication and installation purpose.

Multiple views, including top, back, left, right, and isometric, provide a good understanding of the structure mounted on a specific area or rooftop. These detailed visualizations enable solar installation companies to leave a professional and lasting impression on their customers.

Solar 2D Structural Dimensional Views

We create precise 2D dimensional views for solar structures, including detailed measurements of structural profiles and layouts. These solar 2d drawings contain different measurements such as solar panel layout length and width, purlin and rafter dimensions, vertical column supports pole heights used in solar elevated sheds, structure tilt angle along with front and back heights, vertical column or pole to pole distance, panel to panel spacing as per user requirements, walkway spacing, cantilever length etc

Solar Structural Bill of Material

A comprehensive bill of material (BOM) is provided for solar structure design. This includes a list of main components such as columns, rafter, purlins, baseplates, concrete pads specifications and quantities, and make it easier to calculate the structure cost and procurement of materials.

Approximate Shadow Visualization

Our shadow visualization service predicts approximate shadows casting and falling on solar panels throughout the day, month & year. This helps to design and place solar mounting structure to get maximum sunlight exposure and perform efficiently throughout the year.

Single Line Diagram

Single Line Diagrams (SLD) are simplified electrical schematics that display the solar system’s wiring and connections of main components like solar pv modules banking, strings made with solar inverters, circuit breakers and SPDs etc. These diagrams are also useful for prestigious housing societies and elite residential areas, like DHA, Bahria Town, as they require specialized electrical compliance drawings for the solar system to be installed.

Many solar installation companies require these diagrams for submission and approval purposes.

3D Video of Solar Structure

3D animated videos of pre-installed solar structures provide a near-realistic visualization and making it easier for clients to understand the design and functionality. These videos serve as a powerful tool to showcase project concepts, create a compelling impression for potential customers.
